Main Principle:
The raw material enters the machine from the top hopper, by the vibration force from the vibrator, raw material will glide down along the channel, drop into the observation area, pass through the area between background plate and sensor. Under the function of light, according to the light strong and weak, and color change, system will generate output signal to force solenoid valve to blow out the different color material into bad material hopper, the good one drop into the good material hopper.

Main Parameter:
Camera pixel: 2048px
Capacity: 4-6t (capacity varied according to the moisture, impurity content, quality and size of the peanut)
Chutes: 6
Camera: 12
Sorting accuracy: >99.9%
Optimal carryout rate: >8: 1
Air pressure: ≥ 0.6-0.8Mpa
Host power: 3.5kw
Air consumption: 3500L/min
Weight: 1000kg
Dimension: 2460*1650*2200mm

Main Features:
1. Equipped with high-end 2048 pixel CCD camera, can distinguIsh spots which are less
Than 0.04mm2, glasses and resin etc, increasing sorting impression to a higher level.
2. Reasonable heat output device, ensure all spare parts be working in the room temperature,
SNR is better, not only increased the accuracy of sorting, but also extended the life of machine.
3. More intelligent software, can distinguish all kinds of heterochrosis grain easily and totally
Improved the accuracy of selection.
4. Humanization ture colour screen, visual effect is more clear, operation is more easier.
5. Professinal high frequency ejectors, save more air, reaction velocity is faster, rate of
Accuracy is higher, and longer life, working with intelligent software, ensuring the good rejection
And excellent accuracy.
